O2 transmitters can be used in clean rooms to monitor the oxygen levels in the air and ensure that they remain within safe limits. This is important as changes in oxygen levels can affect the behaviour and growth of microorganisms and other sensitive materials in the room. O2 transmitters can also be used to detect leaks or other issues with the ventilation system that could lead to the introduction of contaminants into the clean room.
| Parameters | Description |
| Make | MULTITECH |
| Target Gases | Oxygen (O2) |
| Oxygen Range | 0 to 100% O2 |
| Accuracy | ± 1% F.S. |
| Input Power | 24 VDC |
| Output | 4-20 mA |
| Display | Digital Display 7 Segment |
| Operating Temperature Range | 5 to 40°C and 10 – 90 % RH |
| Response Time | Approx. 15 seconds |
| Sensing Method | Galvanic Cell |
| Sensor Type | Galvanic Cell Type , quick response, no CO2 influence |
| Output Load | 500 Ω (current), > 2K Ω (voltage) |
| Sensor Life expectancy | Approx. 4 years (at 20?C in normal air) |
| Enclosure | ABS Plastic |
| Warranty | 12 Months Manufacturer Warranty |
- O2 transmitters measure and provide real-time readings of oxygen (O2) levels in the environment.
- They are commonly used in various industries, including medical, industrial safety, and environmental monitoring.
- The transmitters include specialized sensors for accurate detection of oxygen levels.
- Some O2 transmitters may feature a display for convenient access to current oxygen readings.
- Additional features can include data logging, alarm notifications, and integration with control or safety systems.
